Lesson 1.7: Clipping

In this lesson, you will learn how to make clips of videos. It will be similar to using the -ss and -t command line options with ffmpeg. All the code for this tutorial can be found here.

Inital Setup

start_sec = strtod(argv[1], NULL);
in_filename = argv[2];
duration_sec = strtod(argv[3], NULL);
out_filename = argv[4];

if ((ret =
  avformat_open_input(&in_fmt_ctx, in_filename, NULL, NULL)) < 0)
{
  fprintf(stderr, "Failed to open input video file: '%s'.\n",
    in_filename);
  goto end;
}

if ((ret = avformat_find_stream_info(in_fmt_ctx, NULL)) < 0) {
  fprintf(stderr, "Failed to retrieve input stream info.");
  goto end;
}

if ((ret = avformat_alloc_output_context2(&out_fmt_ctx,
  NULL, NULL, out_filename)))
{
  fprintf(stderr, "Failed to allocate output format context.\n");
  goto end;
}

First we assign our command line arguments to our variables. The first argument will be the time in seconds that we will seek to before we beginning reading frames from the input file. It is like the -ss option in ffmpeg. We use the strtod function to convert the input, which is a char by default, into a double. Then, as usual, we call avformat_open_input on the input file to create an AVFormatContext for the input and avformat_alloc_output_context2 with the output filename specified by the user to create an AVFormatContext for the output.

Initialize Streams

for (int i = 0; i < in_fmt_ctx->nb_streams; i++) {
  if ((ret = initialize_stream(out_fmt_ctx,
    in_fmt_ctx->streams[i])) < 0)
  {
    fprintf(stderr, "Failed to initialize stream %d.\n", i);
    goto end;
  }

  if (out_fmt_ctx->streams[i]->codecpar->codec_type ==
    AVMEDIA_TYPE_VIDEO)
  {
    video_idx = i;
  }
}

if (video_idx == -1) {
  fprintf(stderr, "Failed to find video stream.\n");
  goto end;
}

Now we loop through all the streams in the input and pass each one to the initialize_stream function. When we find the video stream, the record the index in video_idx because we use a video frame to determine when to start reading frames from the input to the output. The output video, like all video, must start with a keyframe. If for some reason we haven’t found a video stream after looping through all the streams, we fail.

int initialize_stream(AVFormatContext *out_fmt_ctx,
  AVStream *in_stream)
{
  AVStream *out_stream;
  int ret = 0;

  if (!(out_stream = avformat_new_stream(out_fmt_ctx, NULL))) {
    fprintf(stderr,
      "Failed to allocate output stream for input stream.\n");
    ret = AVERROR(ENOMEM);
    return ret;
  }

  if ((ret = avcodec_parameters_copy(out_stream->codecpar,
    in_stream->codecpar)) < 0)
  {
    fprintf(stderr,
      "Failed to copy codec parameters for input stream.\n");
    return ret;
  }
  out_stream->codecpar->codec_tag = 0;

  if ((ret = av_dict_copy(&out_stream->metadata,
    in_stream->metadata, AV_DICT_DONT_OVERWRITE)) < 0)
  {
    fprintf(stderr,
      "Failed to copy metadata for input stream.\n");
    return ret;
  }
  return ret;
}

The initialize_stream function is pretty standard. It takes in the input stream that will be used to copy parameters, and the output context that the new stream will be added to. We use avformat_new_stream to create the new stream and avcodec_parameters_copy to copy codec parameters from the input stream to the output stream. We set codec_tag to 0 so it will be set properly by the muxer. Finally, we use av_dict_copy to copy stream metadata from the input stream to the output stream.

Seek Frame

start_ts =
  start_sec *
  in_fmt_ctx->streams[video_idx]->time_base.den /
  in_fmt_ctx->streams[video_idx]->time_base.num;

if ((ret =
  av_seek_frame(in_fmt_ctx, video_idx, start_ts,
    AVSEEK_FLAG_BACKWARD)) < 0)
{
  fprintf(stderr, "Failed to seek to start frame.\n");
  goto end;
}

Next, we convert the start time in seconds into a timestamp using the timebase of the video stream. Then we call av_seek_frame to seek to the closest keyframe to the timestamp.

Make Clip

while ((ret = av_read_frame(in_fmt_ctx, pkt)) >= 0)
{
  if (
    pkt->dts < 0 ||
    pkt->pts < 0
  ) {
      av_packet_unref(pkt);
      continue;
    }

  in_stream = in_fmt_ctx->streams[pkt->stream_index];
  out_stream = out_fmt_ctx->streams[pkt->stream_index];

  if (first_dts_set == NOT_SET)
  {
    if (pkt->stream_index == video_idx)
    {
      if (!(pkt->flags & AV_PKT_FLAG_KEY)) {
        av_packet_unref(pkt);
        continue;
      }

      first_dts = pkt->dts;
      first_dts_set = SET;
      duration_ts = av_rescale_q(duration_sec * AV_TIME_BASE,
        AV_TIME_BASE_Q,
        in_fmt_ctx->streams[video_idx]->time_base);
      end_ts = first_dts + duration_ts;
    }
    else {
      av_packet_unref(pkt);
      continue;
    }
  }

  if (pkt->dts > end_ts) {
    av_packet_unref(pkt);
    break;
  }

  pkt->pts = av_rescale_q(pkt->pts - first_dts,
    in_stream->time_base, out_stream->time_base);

  pkt->dts = av_rescale_q(pkt->dts - first_dts,
    in_stream->time_base, out_stream->time_base);

  pkt->duration = av_rescale_q(pkt->duration,
    in_stream->time_base,out_stream->time_base);

  pkt->pos = -1;
  if ((ret = av_interleaved_write_frame(out_fmt_ctx, pkt)) < 0) {
    fprintf(stderr, "Failed to write packet to file.\n");
    goto end;
  }

  av_packet_unref(pkt);
}

Once we’ve allocated an AVPacket, opened the output file, and written the file header, we are ready to start reading packets from the input file. If we read any packets with negative timestampes, we ignore them. Then we check if first_dts_set is SET. This value tells us if first_dts is set, which is the decode time stamp of the frame that will be the first frame of clip. av_seek_frame does not always seek perfectly to a keyframe so we need to check this ourselves before we start reading writing frames to the output.

If first_dts is not set, we check if the current frame is from the video stream beause we are looking for a video keyframe. Then we check if the current frame is a keyframe with the AV_PKT_FLAG_KEY flag. If not, we go to the next frame. If it is a keyframe, then this is the first video key frame we’ve read from the input file. We set first_dts to the dts of the current frame. We set first_dts_set to SET so we know we’ve found the first_dts. Then we rescale the duration_sec to the timebase of the the video stream. Finally, we calculate the end_ts by adding duration_ts to first_dts. This is the timestamp that will tell us once we`ve reached the desired length for the clip.

Now that we have found the starting keyframe to start the clip from, and we know when to end the clip, we first check if the current frame’s dts is past end_ts. If so, we just stop the loop. If not, we rescale the pkt’s timestamps to the output timebase, just like usual, except we first subtract the value of first_dts from the current timestamp so that every timestamp for the entire video will be offset by the same number and timestamps will start at 0.

Then we set pkt->pos to -1 and write the frame to the output file. Once that’s done, we write the trailer and do our cleanup and we’re done. The output file should now contain a clip of the original file that begins at the closest video key frame to the timestamp specified by the user with a length equal to the duration specified by the user.

The next lesson will be the start of Section 2 and we will begin learning about transcoding video and audio.
