In this lesson, you will learn how to output multiple files. You will take in a video file, loop through all the streams, and output each stream into it’s own file. All the code for this tutorial can be found here.

Get basename

in_filename = argv[1];
output_dir = argv[2];

if ((ret = avformat_open_input(&fmt_ctx, in_filename, 0, 0)) < 0)
{
  fprintf(stderr, "Failed to open input file '%s'.\n",
    in_filename);
  goto end;
}

if ((ret = avformat_find_stream_info(fmt_ctx, 0)) < 0) {
  fprintf(stderr, "Failed to retrieve input stream info.");
  goto end;
}

slash = strrchr(in_filename, '/');
if (slash) in_filename = ++slash;

if ((ret = get_len_basename(&len_basename, in_filename)) < 0) {
  printf("Failed to get length of input file basename.\n");
  goto end;
}

if (!(basename = av_mallocz((len_basename + 1) * sizeof(char)))) {
  printf("Failed to allocate memory for basename.\n");
  ret = AVERROR(ENOMEM);
  goto end;
}
strncpy(basename, in_filename, len_basename);

This command takes in the path to a video a file and the path to a directory where the output files will be stored. The name of each file will have the same base name as the input file with an extension that matches the codec of that stream. Each file will use the matroska format.

In the code, we first store the command line input values in in_filename and output_dir. Then, like always, we use avformat_open_input and avformat_find_stream_info to open the input file get info about it. Next, we parse the in_filename string to get the basename of the input file. We use strrchr to find the last instance of the character / in case the value is a path. If no instance of the character is found, strrchr will return null. Otherwise, slash will contain a pointer that points to the last instance of the character. We check if it’s null and if not, we set in_filename to point to the next sport in memory after where slash points to, which will be the first character of the base name of the input file.

int get_len_basename(size_t *len_basename, const char *filename)
{
  const char *slash;
  const char *dot;
  const char *end;
  size_t filename_length;
  size_t ext_length;

  slash = strrchr(filename, '/');
  if (slash) filename = ++slash;

  dot = strrchr(filename, '.');
  if (!dot || dot == filename) {
    fprintf(stderr, "Invalid file name.\n");
    return -1;
  }

  for (end = filename; *end; end++);
  filename_length = end - filename + 1;

  for (end = dot; *end; end++);
  ext_length = end - dot + 1;

  *len_basename = filename_length - ext_length;
  return 0;
}

Now that we know where the base name starts, we need to figure out where it ends. In order to know that we need to know how long the base name is so we use the get_len_basename function. First, we find the location of the .. There must be a . present in the filename and it can’t be the first character in the filename. Then we find the end of the file and subtract the beginning to get the length of the entire filename. Then we subtract dot from the end to get the length of the extension. Then we subtract ext_length from filename_length and that gives us the length of the basename.

Back in the main fuction, now that we know how long the base name is, we can use the av_mallocz function to allocate the basename variable and read len_basename number of characters from in_filename.

Initialize Streams

typedef struct StreamContext {
  char *filename;
  AVFormatContext *fmt_ctx;
  AVStream *in_stream, *out_stream;
  int stream_idx;
} StreamContext;

// in main
if (!(streams = av_calloc(fmt_ctx->nb_streams,
sizeof(StreamContext *))))
{
  fprintf(stderr,
    "Could not allocate memory for streams array.\n");
  ret = AVERROR(ENOMEM);
  goto end;
}

// av_dump_format(fmt_ctx, 0, in_filename, 0);

for (i = 0; i < fmt_ctx->nb_streams; i++)
{
  if (!(streams[i] = av_mallocz(sizeof(StreamContext)))) {
    fprintf(stderr, "Could not allocate memory "
      "for streams for stream '%d'.\n", i);
    ret = AVERROR(ENOMEM);
    goto end;
  }

  streams[i]->filename = NULL;
  streams[i]->stream_idx = i;
  if ((ret =
    init_stream(streams[i], fmt_ctx, output_dir, basename)) < 0)
  {
    goto end;
  }
}

We define a StreamContext struct that will contain information about each stream read from the input file. In the main function, after getting the basename, we allocate the streams array will will contain a pointer to a StreamContext struct for each stream in the fmt_ctx->nb_streams. Next, we allocate the StreamContexts. We initialize the filename to be null and the stream_idx field will be the same as the stream index of the fmt_ctx->streams array that this each StreamContext will be copying data from. Next we call the init_stream function to initialize the AVFormatContext for the output of the current stream.

int init_stream(StreamContext *stream_ctx,
AVFormatContext *fmt_ctx, const char *output_dir,
const char *basename)
{
  int ret;
  const char *ext, *title;

  stream_ctx->in_stream =
    fmt_ctx->streams[stream_ctx->stream_idx];

  ext =
    avcodec_get_name(stream_ctx->in_stream->codecpar->codec_id);

  if ((ret = make_output_filename(stream_ctx, output_dir,
    basename, ext)) != 0)
  {
    fprintf(stderr, "Failed to generate output filename.\n");
    return ret;
  }

  if ((ret = avformat_alloc_output_context2(&stream_ctx->fmt_ctx,
  NULL, "matroska", stream_ctx->filename)))
  {
    fprintf(stderr,
      "Failed to allocate format context for stream %d\n",
      stream_ctx->stream_idx);
    return ret;
  }

  if ((ret = av_dict_copy(&stream_ctx->fmt_ctx->metadata,
    fmt_ctx->metadata, AV_DICT_DONT_OVERWRITE)) < 0)
  {
    fprintf(stderr, "Failed to copy file metadata.\n");
    return ret;
  }

  title = strrchr(stream_ctx->filename, '/');
  if (title) title = ++title;

  if ((ret = av_dict_set(&stream_ctx->fmt_ctx->metadata,
    "title", title, 0)) < 0)
  {
    fprintf(stderr,
    "Failed to set title for output format context.\n");
    return ret;
  }

  if ((ret = copy_chapters(stream_ctx->fmt_ctx, fmt_ctx)) < 0) {
    fprintf(stderr, "Failed to copy chapters.\n");
    return ret;
  }

  if (!(stream_ctx->out_stream =
    avformat_new_stream(stream_ctx->fmt_ctx, NULL)))
  {
    fprintf(stderr,
      "Failed to allocate new output stream for stream %d\n",
      stream_ctx->stream_idx);
    ret = AVERROR(ENOMEM);
    return ret;
  }

  if ((ret =
    avcodec_parameters_copy(stream_ctx->out_stream->codecpar,
      stream_ctx->in_stream->codecpar)) < 0)
  {
    fprintf(stderr, "Failed to copy codec params for stream %d\n",
      stream_ctx->stream_idx);
    return ret;
  }

  if ((ret = av_dict_copy(&stream_ctx->out_stream->metadata,
    stream_ctx->in_stream->metadata, AV_DICT_DONT_OVERWRITE)) < 0)
  {
    fprintf(stderr, "Failed to copy stream metadata.\n");
    return ret;
  }

  if (!(stream_ctx->fmt_ctx->flags & AVFMT_NOFILE)) {
    if ((ret = avio_open(&stream_ctx->fmt_ctx->pb,
      stream_ctx->filename, AVIO_FLAG_WRITE)) < 0)
    {
      fprintf(stderr, "Failed to open file for stream %d\n",
        stream_ctx->stream_idx);
      return ret;
    }
  }

  if ((ret =
    avformat_write_header(stream_ctx->fmt_ctx, NULL)) < 0)
  {
    fprintf(stderr,
      "Error writing header to file for stream %d\n",
      stream_ctx->stream_idx);
    return ret;
  }

  return 0;
}

First, we get a reference to the AVStream from fmt_ctx->streams that the output stream being initialized will be copying from. Next, we use the avcodec_get_name function to get the name of the codec that was used for the current stream as a string and will be used as the extension for the output file. Then we call the make_output_filename function which concatenates the output_dir specified on the command line with the basename and the ext.

Next, we allocate an AVFormatContext for the output of the current stream. We specify the matroska format because otherwise avformat_alloc_output_context2 will try to guess the format from the extension. Then we copy all metadata from the input file to the currenct output. Next, we will set the metadata tile for the output file using strrchr to exclude everything before the last /. That way the title will just be the filename and not the entire output directory. Then we copy chapters. Then we create an AVStream for the output stream and copy codec parameters from the input stream to the output stream. Then we copy stream metadata from the input stream to the output stream. Then we open a file that will have the output stream written to and write the header. At this point, the output stream is all ready to start receiving data from the input file.

Copy Streams

if (!(pkt = av_packet_alloc())) {
  fprintf(stderr, "Failed to allocate AVPacket.\n");
  goto end;
}

while ((ret = av_read_frame(fmt_ctx, pkt)) >= 0)
{
  stream_idx = pkt->stream_index;
  pkt->stream_index = 0;
  av_packet_rescale_ts(pkt,
    streams[stream_idx]->in_stream->time_base,
    streams[stream_idx]->out_stream->time_base);

  if ((ret =
    av_interleaved_write_frame(streams[stream_idx]->fmt_ctx,
    pkt)) < 0)
  {
    fprintf(stderr,
      "Error writing packet to file for stream %d\n",
      stream_idx);
    goto end;
  }
  av_packet_unref(pkt);
}

for (i = 0; i < fmt_ctx->nb_streams; i++)
{
  if ((ret = av_write_trailer(streams[i]->fmt_ctx)) < 0) {
    fprintf(stderr, "Error writing trailer for stream %d\n",
      streams[i]->stream_idx);
    goto end;
  }
}

for (i = 0; i < fmt_ctx->nb_streams; i++)
{
  if ((ret = av_write_trailer(streams[i]->fmt_ctx)) < 0) {
    fprintf(stderr, "Error writing trailer for stream %d\n",
      streams[i]->stream_idx);
    goto end;
  }
}

Once we’ve looped through all the streams in the input file and initialized an output context, stream, and file for each, we can start reading data. Like always, we run a while loop that call av_read_frame. We store the original pkt->stream_index value in stream_idx and then set it to 0 because each stream is getting it’s own output file so each stream will be the only stream in the output. We use the stream_idx to get a reference to the StreamContext for output stream that the current pkt will be written to and use the in_stream and out_stream references to rescale the timestamps. Then we use the fmt_ctx reference to write the packet to the output file.

Once we’re done reading all data, we write trailers to all of the output files and that’s it. Each stream from the input file will now be in it’s own file.

In the next lesson we will learn how to make clips of videos. It will be similar to using the -ss and -t command line options of ffmpeg. We will use the av_seek_frame function to seek to a point in the input file and use the AV_PKT_FLAG_KEY flag to make sure that our clips always begin with a keyframe so they can be properly decoded. We will adjust the timestamps of each frame to make sure timestamps of our video start at 0 and we will check the timestamp value to know when to stop reading from the input to get the desired length for the clip.
