Lesson 1.4: Add Subtitles

In this lesson, you will learn how to embed subtitles stored in a text file into a video file. This is similar to the example in the previous lesson example the data in the file will be interpreted as a stream, not as metadata. As with the previous lesson, there are test videos in the videos/inputs folder and test commands in the run.sh file. Running these commands will embed the subtitle information for subtitles.vtt into the output file as a subtitle stream. The vtt format is only supported in the mkv, mp4, and webm formats. All the code for this tutorial can be found here.

Subtitle File Structure

WEBVTT

00:00:07.549 --> 00:00:09.885
  <u><i>I know kung fu</i></u>

00:00:10.844 --> 00:00:11.720
  <b>Show me</b>

The file should always start with WEBVTT to indicate to any software reading the file that it contains webvtt subtitles. However, avformat_open_input is smart enough to know these are webvtt subtitles if the file extension is .vtt. Even if it has the extension .txt, you can still specify that the file is webvtt by using av_find_input_format("webvtt") and passing the AVInputFormat returned to avformat_open_input.

Each subtitle starts with a timestamp in the format HH:MM:SS.sss. The start timestamp is listed first, followed by the --> symbol, followed by the end timestamp. Any lines of text following the timestamps will be displayed on screen between these timestamps. A blank line indicates the end of that subtitle. Some basic html tags are supported in mkv and webm. For more information about the construction of webvtt files, check out the spec.

Opening Subtitle File

const char *v_filename, *s_filename, *out_filename, *title;

AVFormatContext *v_fmt_ctx = NULL, *s_fmt_ctx = NULL,
  *out_fmt_ctx = NULL;

const AVInputFormat *s_fmt;

...

s_filename = argv[2];

...

if (!(s_fmt = av_find_input_format("webvtt"))) {
  fprintf(stderr, "Failed to find format for subtitle file.\n");
  ret = AVERROR_UNKNOWN;
  goto end;
}

if ((ret = avformat_open_input(&s_fmt_ctx, s_filename,
  s_fmt, NULL)) < 0)

  fprintf(stderr, "Failed to open subtitle file: '%s'.\n",
    s_filename);
  goto end;
}

Opening a subtitle is almost identical to opening a chapter file from the last example. The only difference is that we are specifying the webvtt format to av_find_input_format. As explained above, this is only necessary the subtitle file doesn’t have a .vtt extension and doesn’t start with WEBVTT. Otherwise we could just pass NULL to avformat_open_input for the format.

Writing Subtitle Data

while ((ret = av_read_frame(s_fmt_ctx, pkt)) >= 0)
{
  in_stream = s_fmt_ctx->streams[pkt->stream_index];
  out_stream = out_fmt_ctx->streams[SUBTITLE_STREAM_IDX];

  av_packet_rescale_ts(pkt, in_stream->time_base,
    out_stream->time_base);
  pkt->stream_index = SUBTITLE_STREAM_IDX;
  pkt->pos = -1;

  if ((ret = av_interleaved_write_frame(out_fmt_ctx, pkt)) < 0) {
    fprintf(stderr, "Failed to write subtitle packet to file.\n");
    goto end;
  }

  av_packet_unref(pkt);
}

Unlike chapters, subtitles are not stored as metadata, they stored as a stream, similar to how audio and video data are stored. This means to copy subtitles we need to run a loop that calls av_read_frame, just like we do to copy the video and audio. We pass in s_fmt_ctx to read frames from the subtitle file and they are written into the stream specified by SUBTITLE_STREAM_IDX in the output file.

In the next lesson you will learn how to take in multiple video files and dynamically choose which streams to include in the output based on user input. This will be similar to how the -map option works in ffmpeg.
