Lesson 1.3: Add Chapters

In this lesson, you will learn how add chapter markers to a video file by storing chapter information in a text file and inputting the file into avformat_open_input. As with the previous lesson, there are test videos in the videos/inputs folder and test commands in the run.sh file. Running these will inject the chapter information from chapters.txt into the input file and produce a new file with chapter markers, depending on whether the output format supports chapters. All the code for this tutorial can be found here.

Chapter File Structure

;FFMETADATA1
[CHAPTER]
TIMEBASE=1/1000
START=0
END=6000
title=Introduction
hi=bye

[CHAPTER]
TIMEBASE=1/1000
START=5000
END=10000
title=Main Content

[CHAPTER]
TIMEBASE=1/1000
START=10000
END=12815
title=Conclusion

The first line in the chapters.txt file is ;FFMETADATA1. This will help avformat_open_input auto detect the format when opening the file. Next, each chapter marker starts with the [CHAPTER] indicator. Next, we must specify the timebase. Here we are specifying that the timestamps will be in milliseconds. If this value is not provided, the default value is 1/1,000,000,000. Next, we must specify a START time and an END time. The end time must come after the start time for the same chapter, however, the end time can come after the start time of the next chapter. For mp4, mov, and wmv, the end time listed in the files metadata will be the start time of the next timestamp, regardless of the value stated in the chapters.txt file, unless it is the last chapter. For mkv and webm, the end time listed in the files metadata will be the value stated in the chapters.txt file, but the actual chapter marker when playing the file will be at the start of the latter chapter, not at the end of the former. mkv also supports arbitrary metadata values such as hi=bye. These values will be igonred by the other formats.

Opening Chapter File

const char *v_filename, *ch_filename, *out_filename, *title;

AVFormatContext *v_fmt_ctx = NULL, *ch_fmt_ctx = NULL,
  *out_fmt_ctx = NULL;

const AVInputFormat *ch_fmt;

...

ch_filename = argv[2];

...

if (!(ch_fmt = av_find_input_format("ffmetadata"))) {
  fprintf(stderr, "Failed to find format for chapter file.\n");
  ret = AVERROR_UNKNOWN;
  goto end;
}

if ((ret = avformat_open_input(&ch_fmt_ctx,
  ch_filename, ch_fmt, NULL)) < 0)
{
  fprintf(stderr, "Failed to open chapter file: '%s'.\n",
    ch_filename);
  goto end;
}

The first major difference in this example is that we are taking in two inputs instead of one. We must declare an AVFormatContext struct that will hold information about the chapters.txt file and an AVInputFormat struct that will hold information about the format of the file. We assign the second command line argument as the name of the chapters file.

We then call av_find_input_format specifying the ffmetadata format and assign the return value to ch_fmt. Technically, in this case it is not necessary to specify the format becuase the file begins with ;FFMETADATA1 but if it didn’t, avformat_open_input would still be able to parse it. I just wanted to show two different ways of indicating what type of file this is.

Now we can call avformat_open_input passing in the filename and format. Information about the file will be populated in ch_fmt_ctx including a chapters array just like the chapters array from the last example on the video file that already had chapter information.

Adding Chapters

if ((ret = copy_chapters(out_fmt_ctx, ch_fmt_ctx)) < 0)
{
  fprintf(stderr, "Failed to copy chapters.\n");
  goto end;
}

The next major difference is that when we call copy_chapters, we pass in the AVFormatContext for the chapters.txt file instead of the video file. The copy_chapters function is identical to the fuction in the previous example. At this point, we have now injected chapter information into out_fmt_ctx, only the information came from a text file and not an input video file. From here on, the rest of the files is identical to the code from the previous example.

In the next lesson, we will learn how to inject subtitles into a file. The process will be fairly similar to this one. We will have two inputs, the input video file and another text file with subtitle information. The file will be parsed into an AVFormatContext struct that will have a subtitle stream on it just like if we had input a video file that had a subtitle stream on it. This stream will be muxed into the output file.
